3 - 16
DIAGRAMS
Finisher PS20(stacker paper 0), PS5
(stacker conveyance passing) and
PS6 (Paper exit 1) are ON.
PS20(stacker paper 0), PS6(paper
exit 1), PS5 (stacker conveyance
passing) and PS4(FIN entrance
passing) are ON.
PS20(stacker paper 0) and PS1
(printer paper exit) are ON.
PS20(stacker paper 0), PS1
(Printer paper exit) and PS4 (FIN
entrance passing) are ON.
PS20(stacker paper 0), PS1
(printer paper exit) and PS5
(stacker conveyance passing) are
ON.
PS20(stacker paper 0), PS1
(printer paper exit), PS5(stacker
conveyance passing) and PS4(FIN
entrance passing) are ON.
PS20(stacker paper 0), PS1(printer
paper exit) and PS6(paper exit 1)
are ON.
PS20(stacker paper 0), PS1
(Printer paper exit), PS4 (FIN
entrance passing) and PS6(paper
exit 1) are ON.
PS20(stacker paper 0), PS1
(Printer paper exit), PS5 (stacker
conveyance passing) and
PS6(paper exit 1) are ON.
PS20(stacker paper 0), PS1(printer
paper exit), PS6(paper exit 1), PS5
(stacker conveyance passing) and
PS4 (FIN entrance passing) are
ON.
Finisher/main body is
stopped immediately.
Remove the jammed
paper off the
finisher/main body.
Classifica-
tion
Jam
code
Causes
Operation when jam
occurs
Method of clearing Jam
Finisher
J72-22
J72-23
J72-24
J72-25
J72-26
J72-27
J72-28
J72-29
J72-30
J72-31
When
Stationary
