3 - 17
DIAGRAMS
Finisher PS17(stapler R HP) is not turned
ON within a certain period after
M10 (stapler F) is ON.
PS15(stapler R HP) is not turned
ON within a certain period after M9
(stapler R) is ON.
PS15(stapler R HP) and PS17
(stapler F HP) are not turned ON
within a certain period after M9
(staper R) and M10 (stapler F) are
ON.
PS4 (FIN entrance passage) does
not go ON after PS25 (paper exit)
goes ON/OFF.
PS6 (paper exit 1) does not go ON
after PS4 (FIN entrance passage)
goes ON/OFF. (only in sort mode)
PS5 (stacker conveyance
passage) does not go ON after
PS4 (FIN entrance passage) goes
ON/OFF. (only in staple mode)
PS5 (stacker conveyance
passage) does not go OFF after it
goes ON. (only in staple mode)
PS6 (paper exit 1) does not go ON
within the specified period after M7
(paper feed roller) goes ON. (only
in staple mode)
Finisher/main body is
stopped immediately.
Remove the jammed
paper off the
finisher/main body.
Classifica-
tion
Jam
code
Causes
Operation when jam
occurs
Method of clearing Jam
Finisher
When
operating
J72-49
J72-50
J72-51
J72-65
J72-66
J72-67
J72-68
J72-70
To Next Page
