DIAGRAMS
Causes
Operation in case of
warning occurrence
Releasing
method
Classifica-
tion
Estimated abnormal parts
Warning
code
Main body
The main unit stops sud-
denly while copying is in
progress. The main relay
is off and none of the keys
respond.
E46-0
E46-2
E46-3
E46-6
E46-8
E46-11
E46-12
DCPS (DC power supply) unit
Write unit
IPB (Image Processing Board)
E-RDH (Electronic RDH
Processing Board)
IPB (Image Processing Board)
E-RDH (Electronic RDH
Processing Board)
CB (Control Board)
DCPS (DC power supply) unit
Write unit
IPB (Image Processing Board)
IPB (Image Processing Board)
CB (Control Board)
IPB (Image Processing Board)
E-RDH (Electronic RDH
Processing Board)
CB (Control Board)
Turn SW1 (Main)
off and then on
again. Remove
any paper jams.
processing
error
An error was detected during
sub-scan beam correction
APC.
FIFO error in E-RDH (Electronic
DRH Processing Board) (dur-
ing compression).
FIFO error in E-RDH (Electronic
DRH Processing Board) (dur-
ing expansion).
AHA expansion error in E-RDH
(Electronic DRH Processing
Board).
INDEXSB (Index Sensor
Board) error.
When no change is seen in
INDEXSB output during APC
execution.
Insufficient parameter setting
time error.
Incomplete compression error.
