3 - 23
DIAGRAMS
Causes
Operation in case of
warning occurrence
Releasing
method
Classifica-
tion
Estimated abnormal parts
Warning
code
Main body
Only during idling, it
occurs. M/C stops
instantaneously.
Occurs only during
scanning. M/C stops
instantaneously.
Occurs only during
printing. M/C stops
instantaneously.
Occurs only during
printing. M/C stops
instantaneously.
Occurs only during
idling. M/C stops
instantaneously.
Occurs only during
printing. M/C stop
instantaneously.
E47-1
E47-2
E47-3
E47-4
E47-5
E47-6
IPB (Image processing
board)
Bundle
IPB (Image processing
board)
M40 (Laser correction
motor)
CB (Control board)
Turn the main
switch from
OFF to ON.
processing
CPU error
AGC conclusion is not
returned from the
imageprocessing .
A "scan OK" signal is not
returned from the CPU in the
IPB (image processing
board).
The print OK signal is not
returned from the CPU in the
IPB (image processing
board).
The page memory acquisition
OK signal is not returned
from the CPU in the IPB
(image processing board).
"Sub-scanning beam
correction completed" signal
is not returned from the CPU
in the IPB (image processing
board).
"Printer job OK" signal is not
returned from the CPU in the
IPB (image processing
board).
To Next Page
