TRANSMISSION
Ch 2 page 128 Ch 2 page 129
TRANSMISSION
TRANSMISSION
Ch 2 page 128 Ch 2 page 129
TRANSMISSION
Figure 93
Figure 96
Figure 95
Figure 94
Mount shim s = 0,3 mm (see Example B
2,
Page 2.11) with
grease.
Install shaft seal (Arrow), using driver.
At application of the prescribed driver (S), the exact installation
position is obtained !
Grease the sealing lip of the shaft seal !
Wet outer diameter with spirit !
(S) Driver 504163
Introduce flange shaft until contact is obtained.
Heat bearing inner race.
(S) Hot-air blower 230 V 504193
(S) Hot-air blower 115 V 504194
