TRANSMISSION
Ch 2 page 228 Ch 2 page 229
TRANSMISSION
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
TRANSMISSION
Ch 2 page 228 Ch 2 page 229
TRANSMISSION
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
Figure 373
Figure 376
Figure 375
Figure 374
Insert bearing outer races-KV/K1, -KR/K2 and -K3/K4 into the
housing bores until contact is obtained, see arrows.
Check again installation position of countershaft gear (arrow) and
correct, if necessary.
Position clutch-KR/K2.
Position clutchKV/K1 by means of lifting device.
(S) Set of eye bolts 504182
