164
c Overall Wiring Diagram
Chap.8
3) Main P.W.B. CN3
MAIN PWB
RED RED
RED BLACK
N4-W106*
24V 24V 24V 24V 24V
RED RED WHITE BROWN ORANGE BLACK BROWN YELLOW WHITE BROWN ORANGE BLACK BROWN YELLOW RED BLACK
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16
GATE SOL.
N4-X100*
CN3
SCORE M.
N4-X102*
LEFT SLIT.
M2-X101*
FEED STEPPING M.
M2-X101*
4) Main P.W.B. CN4
BROWN BLUE
BROWN BLUE WHITE BLUE BROWN BLUE WHITE BLUE BROWN BLUE WHITE BLUE WHITE BLUE
N4-W107*
N4-W108*
N4-W108*
N4-W109* N4-W109* N4-W123* N4-W110* N4-W111*
GND GND GND GND GND GND GND GND
BROWN BLUE WHITE BLUE BROWN BLUE WHITE BLUE BROWN BLUE WHITE BLUE BROWN BLUE WHITE BLUE
5V GND 5V GND
RED
WHITE
BLUE
RED
ORANGE
BLUE
1 2 3 1 2 3
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
PPS1 PPS3PPS2 PPS4
CN4
LEFT CEN.
SEN.
LEFT SLIT.
SEN.
MAIN PWB
