165
c Overall Wiring Diagram
Chap.8
5) Main P.W.B. CN5
CCD
N4-X103*
GND 5V
BLACK RED BLUE GREEN GRAY WHITE BROWN ORANGE PURPLE YELLOW
1 2 3 4 5 6 7 8 9 10
CN5
MAIN PWB
6) Main P.W.B. CN6
MAIN PWB
CUTTER UNIT
L8-X1090
FEED LED
RED RED YELLOW WHITE
GND
YELLOW WHITE
RED BLACK YELLOW YELLOW
YELLOW
YELLOW
YELLOW
YELLOW
RED BLUE
N4-W112*
N4-W113*
N4-W119*
N4-W120*
N4-X101*
L8-X1010
L8-X1010
24V 24V GND 24V
RED RED WHITE YELLOW RED BLACK YELLOW YELLOW WHITE YELLOW RED BLUE
BLACK BLACK
1 2 3 4 5 6 7 8 9
10 11 12
SLIT M.2
CN6
ROLL SOL. SLIT M.1
POSITON SW
CUTTER M.
L8-X1110
COVER SW
COVER SW
24V 24V 24V
