167
c Overall Wiring Diagram
Chap.8
9) Main P.W.B. CN9
10) Main P.W.B. CN10
MAIN PWB
N4-W116*
24V 24V 5V GND
WHITE BROWN ORANGE BLACK BROWN YELLOW RED PURPLE BLUE
1 2 3 4 5 6 7 8 9
1 2 3
CN9
OPTION
SEN.
OPTION
SLT.1
MAIN PWB
MEMORY PWB
K9-V212*
N4-W117*
WHITE YELLOW ORANGE BLUE GREEN RIGHT BLUE RED RED
GND 5V
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18
CN1
CN10
