NETGEAR FVS318G User Manual

LAN Configuration
104
NETGEAR ProSAFE VPN Firewall FVS318G v2
5. Click the Apply button.
Your changes are saved.
IPv6 DMZ Address Pools
If you configure a stateful DHCPv6 server for the DMZ, you must add local DHCP IPv6
address pools so the DHCPv6 server can control the allocation of IPv6 addresses in the
DMZ.
 To add an IPv6 DMZ address pool:
1. Log in to the unit:
a. In the address field of any of the qualified web browsers, enter
https://192.168.1.1.
The NETGEAR Configuration Manager Login screen displays.
b. In the User
name field, enter admin and in the Password / Passcode field, enter
password.
Use lowercase letters. If you changed the password, enter your persona
lized
password. Leave the domain as it is (geardomain).
c. Click the L
ogin button.
The Router Status screen displays. After five minutes of inactivity,
which is the default
login time-out, you are automatically logged out.
DHCP Status
(continued)
DNS Server Select one of the DNS server options from the lists:
• Use DNS Proxy. The VPN firewall acts as a proxy for all
DNS requests and communicates with the ISP’s DNS
servers that you configured on the Broadband ISP Settings
(IPv6) screen (see Configure a Static IPv6 Internet
Connection on
p
age 42).
• Use DNS from ISP.
The VPN firewall uses the ISP’s DNS
servers that you configured on the Broadband ISP Settings
(IPv6) screen (see Configure a Static IPv6 Internet
Connection on p
age 42).
• Use below. When you select this option, the DNS server
fields become available for you to enter IP addresses.
Primary DNS Server Enter the IP address of the primary
DNS server for the DMZ.
Secondary DNS Server Enter the IP address of the
secondary DNS server for the DMZ.
Lease/Rebind
Time
Enter the period after which the DHCP lease is renewed with
the original DHCP server or rebound with another DHCP
server to extend the existing DHCP lease. The default period is
86400 seconds (24 hours).
Table 19. DMZ Setup screen settings for IPv6 (continued)
Setting Description

NETGEAR FVS318G Specifications

General

Power requirements	12V DC, 1.5A
Firewall throughput	250 Mbit/s
Maximum data transfer rate	1000 Mbit/s
HTTP performance	6000 transactions/sec
Wi-Fi	No
DHCP server	Yes
Number of VLANs	256
VPN tunnels quantity	12
WAN connection	Ethernet (RJ-45)
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	9
Ethernet DMZ ports quantity	1
Routing protocols	RIP-1, RIP-2
Supported network protocols	TCP/IP, UDP, ICMP, PPPoE
VPN support	IPsec (ESP), IKE, PKI, HTTPS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, MD5, SHA-1
Internal memory	128 MB
Flash memory	32 MB
Storage media type	Flash
Processor frequency	300 MHz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Cables included	LAN (RJ-45)

Weight and Dimensions

Weight	590 g
Dimensions (WxDxH)	190 x 125 x 35 mm
