NETGEAR FVS318G User Manual

Default Settings and Technical Specifications
403
NETGEAR ProSAFE VPN Firewall FVS318G v2
QoS profiles Normal-Service
Minimize-Cost
Maximize-Reliability
Maximize-Throughput
Minimize-Delay
Content filtering Disabled
Proxy server blocking Disabled
Java applets blocking Disabled
ActiveX controls blocking Disabled
Cookies blocking Disabled
Blocked keywords None
Trusted domains All
VPN IPSec Wizard: IKE policy settings for IPv4 and IPv6 gateway-to-gateway tunnels
Exchange mode Main
ID type Local WAN IP address
Local WAN ID Local WAN IP address
Remote WAN ID Not applicable
Encryption algorithm 3DES
Authentication algorithm SHA-1
Authentication method Pre-shared key
Key group DH-Group 2 (1024 bit)
Lifetime Eight hours
VPN IPSec Wizard: VPN pol
ic
y settings for IPv4 and IPv6 gateway-to-gateway tunnels
Encryption algorithm 3DES
Authentication algorithm SHA-1
Life time One hour
Key group DH-Group 2 (1024 bit)
NetBIOS Enabled
Table 86. VPN firewall factory default configuration settings (continued)
Feature Default Behavior

NETGEAR FVS318G Specifications

General

Power requirements	12V DC, 1.5A
Firewall throughput	250 Mbit/s
Maximum data transfer rate	1000 Mbit/s
HTTP performance	6000 transactions/sec
Wi-Fi	No
DHCP server	Yes
Number of VLANs	256
VPN tunnels quantity	12
WAN connection	Ethernet (RJ-45)
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	9
Ethernet DMZ ports quantity	1
Routing protocols	RIP-1, RIP-2
Supported network protocols	TCP/IP, UDP, ICMP, PPPoE
VPN support	IPsec (ESP), IKE, PKI, HTTPS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, MD5, SHA-1
Internal memory	128 MB
Flash memory	32 MB
Storage media type	Flash
Processor frequency	300 MHz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Cables included	LAN (RJ-45)

Weight and Dimensions

Weight	590 g
Dimensions (WxDxH)	190 x 125 x 35 mm
