4-4
Chapter 4 I/O SETTINGS
ZW
User’s Manual
Chapter 4
I/O Terminal Names and Functions
Electrical Specifications p.4-5
Timing Charts p.4-33
A22 BINARY1 Binary output Red
A23 BINARY0 Orange
A24 GATE GATE signal output Yellow
A25 COM_OUT3 COM3 for output Green
A26 COM_OUT3 Blue
B1 BANK_OUT3 Bank number output Brown
B2 BANK_OUT2 Red
B3 BANK_OUT1 Orange
B4 NC Not used Yellow
B5 BINARY_OUT2 Binary output task
number output
Green
B6 BINARY_OUT1 Blue
B7 NC Not used Purple
B8 NC Gray
B9 NC White
B10 NC Black
B11 NC Brown
B12 COM_OUT2 COM2 for output Red
B13 COM_OUT2 Orange
B14 NC Not used Yellow
B15 NC Green
B16 BINARY_SEL2 Binary output object
task selection input
Blue
B17 BINARY_SEL1 Purple
B18 BANK_SEL3 Bank selection input Gray
B19 BANK_SEL2 White
B20 BANK_SEL1 Black
B21 NC Not used Brown
B22 NC Red
B23 NC Orange
B24 NC Yellow
B25 COM_IN2 COM2 for input Green
B26 COM_IN2 Blue
No. Signal name Description
ZW-XCP2
cable color
