4-8
Chapter 4 I/O SETTINGS
ZW
User’s Manual
Chapter 4
I/O Signal Functions
●
ENABLE output
●
ZERO input
●
RESET input
●
TIMING input
●
LED OFF input
Name Description
ENABLE output This turns ON when the sensor is ready for measurement.
This output is interlocked with the ENABLE indicator.
Name Description
ZERO input This is used to execute and clear a zero reset.
Name Description
RESET input This resets all executing measurements and outputs.
While a RESET is being input, judgment output conforms to the non-
measurement setting.
If this RESET input switches ON while the hold function is used, the state in
effect before the hold function was set will be restored.
Name Description
TIMING input This timing input is for signal input from external devices. Use it for hold
function timing.
Name Description
LED OFF input This LED-OFF signal puts out the measurement LED.
While LED-OFF is being input, the analog output, binary output, and judgment
output conform to the non-measurement setting.
