Processing Item Data List
7-15
ZW
User’s Manual
43 Average 2 Average count 8: Count
256
0: Count 1
1: Count 2
2: Count 4
3: Count 8
4: Count 16
5: Count 32
6: Count 64
7: Count 128
8: Count 256
9: Count 512
10: Count 1024
11: Count 2048
12: Count 4096
Yes Yes
44 Frequency
filter
2 Filter type 0 0: Off
1: Highpass filter
2: Lowpass filter
3: Bandpass filter
Yes Yes
3 Cutoff frequency 1 1 to 999999 (1div: 0.001) Yes Yes
4 Cutoff frequency (upper
limit)
999999 1 to 999999 (1div: 0.001) Yes Yes
5 Cutoff frequency (lower limit) 1 1 to 999999 (1div: 0.001) Yes Yes
45 Differentiation 2 Differentiation mode 0 0: Off
1: On
Yes Yes
3 Differentiation cycle 1 1 to 5000 (ms) Yes Yes
46 Hold 2 Hold mode 0 0: Off
1: Peak
2: Bottom
3: Peak to peak
4: Auto peak
5: Auto bottom
6:
Auto peak to peak
7: Average
8: Sample
Yes Yes
3 Trigger method 0 0: Timing
1: Self-up trigger
2: Self-down trigger
Yes Yes
4 Trigger level 0 -999999999 to
999999999 (nm)
Yes Yes
5 Trigger hys 0.05% of
measurin
g range
0 to 999.999999 (mm) Yes Yes
6 Trigger delay time 1 1 to 5000 (ms) Yes Yes
7 Sampling time 100 1 to 5000 (ms) Yes Yes
8 Trigger delay mode 0 0: Off
1: On
Yes Yes
Unit
number
Processing
Item
Data
numb
er
Palameter
Default
value
Setting range/output
range
Acq
uisiti
on
ena
bled
/
disa
bled
Setti
ng
ena
bled
/
disa
bled
