Chapter 1
MEAS
UREMENT SETUP
Chapter 1
About Installation
and Connection
1-9
ZW
User’s Manual
■
Mutual interference
When using two or more Sensor Heads nex
t to each other
, mutual interference will not
occur if other beam spots
are out
side the
䂓
areas in the
following diagrams.
19 mm
●ZW-S20
●ZW-S40
2 mm
300 μm
34 mm
12 mm
800 μm
36
38
