■ Details displayed on the sub-display
The items listed in the following table appears on the sub-display.
Press the / keys to toggle the display.
Display Details Description
Threshold Displays the HIGH and LOW threshold values.
When displaying a HIGH threshold value, the THRESHOLD-H indicator lights up,
while for a LOW threshold value, the THRESHOLD-L indicator lights up.
Analog output Displays the voltage or current value output in analog format.
The display details for the output destination setting are different for voltage output
and for current output. (Values displayed here are reference values only. These
values differ from actual analog output values.)
Judgment result The judgment result for each task appears.
The TASK1, 2, 3 and 4 judgment results are displayed starting from the left.
H: HIGH
P: PASS
L: LOW
E: ERROR
Resolution Displays the fluctuation width (peak to peak) of the measured value over a fixed
amount of time.
Exposure time Displays the current exposure time.
It ranges from 1 to 5000 s.
Distance Displays the distance from the sensor to a target to measure.
Effective bank Displays the current bank number.
Displayed task Displays the currently selected task number, from TASK1 to TASK4.
The measured value for the selected task appears on the main display.
