Page #97 background imageLoading...
Page #97 background image
Chapter 3 SETTINGS FOR FUNCTIONS
Chapter 3
Setting the Output Conditions
3-19
ZW
User’s Manual
Setting the frequency filter
Set a filter to ignore or detect the changes in a specific frequency in the measured data.
*1 Set the cut-off frequency to a value smaller than one-half of the sampling frequency. Otherwise, the
frequency filter will not function properly. If a value outside of the appropriate range is set, the
frequency filter will be applied with the values included in the range.
*2 If the cut-off frequency values (upper/lower limits) are too close, the frequency bandwidth to be
detected cannot be properly detected.
The sampling frequency is the inverse of the sampling cycle.
The measuring cycle can be viewed in the "System Information" menu.
Checking Information p.3-47
Setting [Display] Description
Lowpass Filter [LO.PASS] Ignores frequency components larger than the specified
cut-off frequency. (Only gradual changes are captured.)
Range of cut-off frequency: 0.001 - 999.999 Hz
*1
(Default value: 0.001)
Highpass Filter [HI.PASS] Detects frequency components smaller than the
specified cut-off frequency. (Sudden changes are
captured.)
Range of cut-off frequency: 0.001 - 999.999 Hz
*1
(Default value: 0.001)
Bandpass Filter [BD.PASS] Detects the frequency components between the cut-off
frequency (lower limit) and the cut-off frequency (upper
limit).
Sets the upper and lower limits of the frequency
bandwidth to be detected.
Range: Upper limit 0.001 - 999.999 Hz
*1
(Default value: 999.999)
Lower limit 0.001 - 999.999 Hz
*1
(Default value: 0.001)
Off [OFF]
(Default value)
Frequency filter is not used.
