7. Double-click the added object.
The setting pane will be displayed in the main pane. Specify settings related to Modbus
TCP
.
● To remove a device that has been added, select the device in the navigator pane and press the
"Delete" key
.
5.5.2 Adding a Protocol to Be Used for the COM Port
This section explains how to add an object of the protocol to be used for the COM port to a
project and set it up.
For example, use the following procedure to add an object of Modbus R
TU to the COM port and
set it up.
1. Right-click the
[Device] object in the navigator pane and then select "Add Device" from the
context-sensitive menu that is displayed.
5.5 Setting up the Communication Function
5-22 WUME-GM1RTXOP-01
