IntelliCenter Control System User’s Guide
36 |
Advanced System Configuration Options: To access the Advanced System
Configuration options, go to Settings > Advanced System Configuration,
page 52.
Settings
Advanced System Configuration Options Summary:
Installation Setup: Configure the IntelliCenter
™
Control System system. Body
Configuration (page 53). Circuits (page 56), Pumps (page 62), Heaters (see
page 72), Valves (page 76), Chemistry (page 78).
Remotes Setup: Add Spa-Side Remote: Select Spa Command, iS4, iS10, or
QuickTouch Spa-Side Remote. See page 80.
Network and WiFi Setup: Configure Ethernet, Connect to a Wireless Network
(SSID), Adjust Wireless Transmit Power, Internet Connection, and Reboot WiFi
Device. See page 84.
IntelliCenter Wireless Remote Setup: Set up the wireless remote. See page 86.
Delay Settings: Valve Delay ON/OFF, Heater Cool Down ON/OFF, Freeze Cycle Time
(min), Spa Freeze Override (min) and Override Delays. See page 87.
System: System Information, Detected Hardware, Firmware update. See page
88.
Import / Export: Import System Configuration, Export System Configuration,
Export Status Logs. See page 89.
Restore Factory Defaults: Overwrite the current system configuration with the
default factory settings. Follow the screen prompts. See page 91.
Setup Wizard: Configure the system using the step-by-step setup wizard assistant.
See page 94.
affect the ability to use your system.
Network and WiFi Setup
Remotes Setup
IntelliCenter Wireless Remote Setup
Import/Export
System
Restore Factory Defaults
affect the ability to use your system.
Wizard

Pentair INTELLICENTER Specifications

General

Expandable	Yes
Energy Management	Yes
Touchscreen Display	Yes
Remote Access	Yes, via Mobile App
User Interface	Touchscreen
Remote Monitoring	Yes
Number of Circuits	Up to 40
Wireless Connectivity	Yes
Power Requirements	120V AC
Enclosure Rating	NEMA 3R
