Pfaff creative icon User Manual

The Multi-Touch Screen
Options for Feed Dogs
1. Feed Dogs Lowered
2. Feed Dogs Up
When auto is selected (recommended) your machine
automatically raises or lowers the Feed Dogs,
depending on the stitch and other selected settings. For
example, the Feed Dogs are lowered when sewing on
buttons or when free-motion sewing.
Select Up and the Feed Dogs will be raised for all
sewing. Select Down and the Feed Dogs will be lowered
for all sewing.
Note: The machine will always lower the Feed Dogs
automatically when raising the presser foot to extra lift
position.
Note: The Feed Dogs options will automatically be reset to
auto at the start of a new project from the Help Center.
Tie-Off Options
Tie-Off Options
These options let you program a Tie-Off at the
beginning and at the end of a stitch. It is also possible to
program a thread cut at the end of a stitch.
Note: For immediate Tie-Off, use the Tie-Off button, found on
the front of the machine.
61

Pfaff creative icon Specifications

General

Stitch Width	9 mm
Needle Positions	37
Lighting	LED
USB Port	Yes
Automatic Thread Cutter	Yes
Built-in Memory	Yes
Maximum Sewing Speed	1050 stitches per minute
Connectivity	WiFi, USB
Needle Threader	Fully Automatic
Bobbin Winding	Separate bobbin winding motor
Screen	10.1" Full Color Touch Screen
Weight	15.6 kg
