9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
11.69
2. Install the fasteners holding the RH and LH center
console panels to the vehicle. Torque fasteners to
specification.
TORQUE
Center Console Panel Fasteners:
3.5 lb-ft (4.7 Nm)
3. Install the center tunnel access cover and fasteners
securing it to the RH and LH center console panels.
4. Install the fasteners holding the passenger grab
handle to the vehicle. Torque fasteners to
specification.
TORQUE
Passenger Grab Handle Fasteners:
6 lb-ft (8 Nm)
UPPER FLOOR PANEL INSTALLATION
1. Install the fasteners holding the upper floor panel to
the main floor panels.
BODY / FRAME
