Promise Technology VTrak M610i User Manual

Chapter 1: Introduction to VTrak
3
Figure 3. VTrak M610i rear view
Figure 4. VTrak M310i and M210i rear view
Architectural Description
The VTrak M610i is a 3U enclosure designed for an IP-based Storage Area
Network (IP SAN) and Direct Attached Storage (DAS). The M310i and M210i are
2U enclosures designed for an IP SAN or DAS.
The M610i, M310i, and M210i subsystems support:
• 1.5 Gb/s SATA disk drives
• 3.0 Gb/s SATA disk drives
Mgmt
IOIOI
iSCSI 2 iSCSI 1
RAID Controller
Power Supply 1 Power Supply 2Cooling Unit 1 Cooling Unit 2
Mgmt
IOIOI
iSCSI 2
iSCSI 1
O
I
O
I
RAID Controller
Power Supply 1 Power Supply 2Cooling Unit 1
with Battery
Cooling Unit 2

Promise Technology VTrak M610i Specifications

General

Brand	Promise Technology
Model	VTrak M610i
Category	Network Storage Server
Language	English
