VTrak M610i, M310i, M210i Product Manual
72
Editing CHAPs
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the iSCSI Management icon.
4. From the CHAP tab dropdown menu, choose Add CHAP.
5. Enter a name in the Name field.
6. Enter a secret of 16 or more characters in the Secret field.
7. Enter the secret again in the Retype Secret field.
8. Select the CHAP type.
Peer to peer is one-way authentication. Local is bi-directional authentication.
9. Click the Submit button.
Deleting CHAPs
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the iSCSI Management icon.
4. From the CHAP tab dropdown menu, choose Delete CHAP.
5. Check the box to the left of the CHAP you want to delete.
6. Click the Submit button.
Pinging iSCSI Connections
This function enables you to ping other network nodes (PCs, servers, etc.)
through VTrak’s iSCSI data ports.
To ping an iSCSI connection:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the iSCSI Management icon.
4. Click the Ping tab in Management view.
5. Enter the IP address you want to ping in the IP Address field.
6. Select the data port (1 or 2) from the Ping Through Port dropdown menu.
7. Click the Submit button.
After a few moments, the result displays in the iSCSI Ping Operation header.
