Promise Technology VTrak M610i User Manual

VTrak M610i, M310i, M210i Product Manual
200
• From the Firmware Update tab dropdown menu, select Download from
TFTP Server.
6. Enter the hostname or IP address of your TFTP server in the field provided.
7. Enter the port number of your TFTP server in the field provided (69 is the
default).
8. Enter the filename of the Firmware Update file in the field provided.
9. Click the Submit button.
10. When the download is completed, click the Next button.
A popup message appears warning you not to reboot the VTrak during the
firmware update procedure.
11. In the popup message, click the OK button.
The update progress displays. Then a popup message appears to tell you to
reboot the VTrak.
12. In the popup message, click the OK button.
13. Restart the VTrak. See “Restarting the Subsystem” on page 201.
Updating Firmware from your PC
To update the firmware from your PC:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Software Management icon.
4. Click the Firmware Update tab.
5. Do one of the following actions:
• Click the Download Flash File from Local File through HTTP option,
then click the Next button.
• From the Firmware Update tab dropdown menu, select Download from
Local File.
6. Enter the filename of the Firmware Update file in the field provided.
Or, click the Browse... button and select the Firmware Update file in the
Open dialog box.
7. Click the Submit button.
Note
After you click the Submit button, if WebPAM PROe displays this
message: error transferring image, you entered an incorrect file
name or an incorrect location. Check the information and try
again.
