Promise Technology VTrak M610i User Manual

Chapter 4: Management with WebPAM PROe
63
To make changes to the iSCSI Data Port settings:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Network Management icon.
4. Click the iSCSI Ports tab in Management View.
5. Click the Port Configuration – Port 1 link or the Port Configuration –
Port 2 link.
6. To enable DHCP, check the DHCP box.
When DHCP is NOT enabled, enter:
• IP address
• Subnet mask
• Gateway IP address
7. To enable jumbo frames, check the Jumbo Frame box.
8. Enter a TCP port number.
The default is 3260.
9. Click the Submit button.
Viewing VLAN Entries
To view the current VLAN entries:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Network Management icon.
4. Click the VLAN tab in Management View.
The Member Interface refers to an iSCSI data port or to the link aggregate
trunk number.
Creating a VLAN Entry
This feature enables you to create a virtual local area network (VLAN) using an
iSCSI data port on your subsystem.
If you plan to aggregate the iSCSI ports, create a link aggregation before you
create the VLAN. See “Creating a Link Aggregation Entry” on page 65.
If you plan to use jumbo frames for the VLAN, enable jumbo frames for the iSCSI
ports before you create the VLAN. See “Making iSCSI Data Port Settings” on
page 62.
