Chapter 8: Troubleshooting
245
LEDs Display Amber or Red
Front Panel
When the power is switched on, the LEDs on the front of the VTrak will light up.
Figure 2. VTrak front panel LED display. The M610i is shown
When boot-up is finished and the VTrak is functioning normally:
• Controller Heartbeat LED blinks once every two seconds.
• Power, FRU, and Logical Drive LEDs display green continuously.
• The RAID Controller LED flashes green if there is activity on a iSCSI port.
See the table below.
Power
Reserved
FRU Status
Logical Drive Status
RAID Controller Activity
Controller Heartbeat
