Promise Technology VTrak M610i User Manual

Chapter 4: Management with WebPAM PROe
71
Making iSNS Settings
To make iSCSI iSNS settings:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the iSCSI Management icon.
4. Click the iSNS tab in Management View.
5. Click the iSNS link.
6. Check the box to enable iSNS.
7. Enter the iSNS server IP address.
8. Enter a new iSNS Port number if required.
Use 1 to 65535.
9. Click the Submit button.
Viewing CHAPs
Challenge Handshake Authentication Protocol (CHAP) is an authentication agent
(typically a network server) sends the client program a random value and an ID
value. Both the sender and peer share a predefined secret. The peer
concatenates the random value, the ID, and the secret and calculates a one-way
hash value. The hash value is sent to the authenticator, which in turn builds that
same string on its side, calculates the sum, and compares the result with the
value received from the peer. If the values match, the peer is authenticated.
To view iSCSI CHAPs:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the iSCSI Management icon.
4. Click the CHAP tab in Management View.
The window displays CHAP information.
Adding CHAPs
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the iSCSI Management icon.
4. Click the CHAP tab in Management View.
