Remote Control
R&S
®
FSPN
383User Manual 1179.4363.02 ─ 01
CONFigure:SNTune:SWEep:DELay[:POINt] <SettlingTime>
This command defines a delay time that allows the DUT to settle when a new tuning
voltage is applied and before the measurement starts.
Parameters:
<SettlingTime> <numeric value>
*RST: 10 ms
Default unit: s
Example: //Define a settling time of a 100 ms
CONF:SNT:SWE:DEL 100MS
Manual operation: See "Defining the settling time" on page 129
CONFigure:SNTune:SWEep:POINts <MeasPoints>
This command defines the number of measurement points for the VCO measurement.
Parameters:
<MeasPoints> <numeric value> (integer only)
*RST: 10
Example: See CONFigure:SNTune:SWEep:SOURce.
Manual operation: See "Defining the sweep range" on page 128
CONFigure:SNTune:SWEep:SOURce <PowerSource>
This command selects the source (connector) which tunes the VCO.
Parameters:
<PowerSource> VAUX
Selects the V
aux
connector as the sweep source.
VSUPly
Selects the V
supply
connector as the sweep source.
VTUNe
Selects the V
tune
connector as the sweep source.
Example: //Selects the V
supply
connector as the tuning source
CONF:SNT:SWE:SOUR VSUP
//Select the type of output at the V
supply
connector
SOUR:VOLT:POW:LEV:MODE VOLT
//Configure a tuning range with 10 measurement points
CONF:SNT:SWE:STAR 0V
CONF:SNT:SWE:STOP 5V
CONF:SNT:SWE:POIN 10
//Turn on the output of the tuning signal
SOUR:VOLT:POW:LEV ON
Common Measurement Settings
