R&S FSPN - Page 393

Remote Control
R&S
®
FSPN
393User Manual 1179.4363.02 ─ 01
Parameters:
<Level> <numeric value>
Default unit: V
Example: //Configure external trigger on trigger port 2
TRIG:SOUR EXT2
TRIG:LEV:EXT2 1.4V
Manual operation: See "Defining the trigger level and frequency" on page 134
TRIGger[:SEQuence]:SLOPe
<Slope>
This command selects the trigger slope.
Parameters:
<Slope> NEGative
Triggering occurs on a falling signal edge.
POSitive
Triggering occurs on a rising signal edge.
*RST: POSitive
Example: //Select trigger slope
TRIG:SLOP POS
Manual operation: See "Defining a trigger slope" on page 135
TRIGger[:SEQuence]:SOURce <Source>
This command selects the trigger source.
Parameters:
<Source> EXTernal | EXT2
External trigger: The measurement starts when the signal
applied to the input connector meets or exceeds a certain level.
FREQuency
Frequency trigger: The measurement starts when the signal
applied to the RF input meets or exceeds a certain frequency.
IMMediate
Free run: No trigger is used.
IQPower
Power trigger: The measurement starts when the signal level
within the demodulation bandwidth rises or falls by a certain
amount.
*RST:
IMMediate
Example: //Select trigger source
TRIG:SOUR FREQ
Manual operation: See "Selecting the trigger source" on page 134
Common Measurement Settings
