R&S FSPN - Page 396

Remote Control
R&S
®
FSPN
396User Manual 1179.4363.02 ─ 01
Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
Parameters:
<Mode> ABSolute
Displays the frequencies in absolute values.
RELative
Displays the frequencies as an offset to the center frequency.
*RST: ABSolute
Example: //Display frequencies in relative terms
DISP:TRAC:Y:MODE REL
Manual operation: See "Scaling the y-axis of the frequency diagram" on page 138
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:PDIVision <Value>
This command defines the range of a single diagram division on the y-axis of the
phase result display.
Prerequisites for this command
●
Phase result display must be available and selected.
Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
Parameters:
<Value> <numeric value>
Default unit: Depends on the selected unit (rad or deg)
Example: //Display 0.5 rad per grid division
DISP:TRAC:Y:UNIT
DISP:TRAC:Y:PDIV 0.5
Manual operation: See "Scaling the y-axis of the phase diagram" on page 138
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RPOSition <Position>
This command defines the position of the reference value on the y-axis.
Prerequisites for this command
●
Phase result display must be available and selected.
Suffix:
<n>
.
1..n
Window
Common Measurement Settings
