Remote Control
R&S
®
FSPN
395User Manual 1179.4363.02 ─ 01
Suffix:
<n>
.
1..n
Window
Parameters:
<Mode> AUTO
Positions the zero phase at the end of the trace (right diagram
border).
MANual
Manual selection the position of the zero phase.
You can define the zero phase position with CONFigure:
TRANsient[:WINDow<n>]:AF:COUPling:RPOint[:X].
*RST: AUTO
Example: //Select zero phase positioning mode
CONF:TRAN:AF:COUP:RPO:MODE AUTO
Manual operation: See "Positioning the zero-phase" on page 139
CONFigure:TRANsient[:WINDow<n>]:AF:COUPling:RPOint[:X]
<Position>
This command defines the position of the zero phase.
Prerequisites for this command
●
Turn on manual selection of the zero phase position (CONFigure:TRANsient[:
WINDow<n>]:AF:COUPling:RPOint:MODE).
●
Select "DC" AF coupling (CONFigure:TRANsient[:WINDow<n>]:AF:
COUPling on page 394).
Suffix:
<n>
.
1..n
Window
Parameters:
<Position> <numeric value>
Default unit: s
Example: //Define position of the zero phase manually
CONF:TRAN:AF:COUP:RPO:MODE MAN
CONF:TRAN:AF:COUP:RPO 1US
Manual operation: See "Positioning the zero-phase" on page 139
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:MODE <Mode>
This command selects how frequencies are displayed on the y-axis.
Prerequisites for this command
●
Frequency result display must be available and selected.
Common Measurement Settings
