Remote Control
R&S
®
FSPN
397User Manual 1179.4363.02 ─ 01
<t> 1..n
irrelevant
Parameters:
<Position> Percentage of the diagram height with 100 % corresponding to
the upper diagram border
*RST: 50
Default unit: PCT
Example: //Shift reference position to top of the diagram
DISP:TRAC:Y:RPOS 100
Manual operation: See "Scaling the y-axis of the phase diagram" on page 138
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RVALue
<RefValue>
This command defines the value assigned to the reference position.
Prerequisites for this command
●
Phase result display must be available and selected.
Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
Parameters:
<RefValue> <numeric value>
*RST: 0
Default unit: Depends on the selected unit (deg or rad)
Example: //Define reference value in rad
DISP:TRAC:Y:UNIT RAD
DISP:TRAC:Y:RVAL 5
Manual operation: See "Scaling the y-axis of the phase diagram" on page 138
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:UNIT <YScalUnit>
This command selects the unit in which the phase results are displayed.
Prerequisites for this command
●
Phase result display must be available and selected.
Suffix:
<n>
.
1..n
Window
<t> 1..n
irrelevant
Common Measurement Settings
