Parameters:
<YScalUnit> DEG | RAD
*RST: RAD
Example: //Select unit for phase results
DISP:TRAC:Y:UNIT DEG
Manual operation: See "Scaling the y-axis of the phase diagram" on page 138
11.6.9.6 Settling Time
CALCulate<n>:SETTling:TIME:STATe..............................................................................398
CALCulate<n>:SETTling:TIME:DIAGram..........................................................................398
CALCulate<n>:SETTling:TIME:TRACe.............................................................................398
CALCulate<n>:SETTling:TIME:FREQuency:LIMit:LOWer...................................................399
CALCulate<n>:SETTling:TIME:FREQuency:LIMit:UPPer................................................... 399
CALCulate<n>:SETTling:TIME:RESult?........................................................................... 399
CALCulate<n>:SETTling:TIME:STATe <State>
This command defines the state of settling time measurement.
Suffix:
<n>
.
irrelevant
Parameters:
<State> ON | OFF | 1 | 0
*RST: 0
Example:
CALC1:SETT:TIME:STAT OFF
CALCulate<n>:SETTling:TIME:DIAGram <Diagram>
This command selects the diagram for settling time calculation.
Suffix:
<n>
.
irrelevant
Parameters:
<Diagram> Number of the diagram
Example:
CALC:SETT:TIME:DIAG 1
CALCulate<n>:SETTling:TIME:TRACe <Trace>
This command selects the trace for settling time calculation.
Suffix:
<n>
.
irrelevant
Parameters:
<Trace> TRACe1 | TRACe2 | TRACe3 | TRACe4 | TRACe5 | TRACe6
