DIAGnostic:SERVice:INPut[:SELect] <Signal>
This command activates or deactivates the use of an internal calibration signal as input
for the R&S FSPN.
Parameters:
<Signal> CALibration
Uses the calibration signal as RF input.
MCALibration
Uses the calibration signal for the microwave range as RF input.
RF
Uses the signal from the RF input.
*RST: RF
Example:
DIAG:SERV:INP CAL
Uses the calibration signal as RF input.
Manual operation: See " NONE " on page 239
See " Calibration Frequency RF " on page 239
See " Calibration Frequency MW " on page 239
See " Calibration Synthesizer 2 " on page 239
DIAGnostic:SERVice:INPut:SYNThtwo[:FREQuency] <Frequency>
This command selects the frequency which the synthesizers are calibrated for.
The command is available when you select the synthesizer as the calibration source
with DIAGnostic:SERVice:INPut[:SELect] on page 485.
Parameters:
<Frequency> Default unit: Hz
Example:
DIAG:SERV:INP:SEL SYNT
DIAG:SERV:INP:SYNT 10MHZ
Manual operation: See " Calibration Synthesizer 2 " on page 239
DIAGnostic:SERVice:STESt:RESult?
This command queries the self-test results.
Return values:
<Results> String of data containing the results.
The rows of the self-test result table are separated by commas.
Example:
DIAG:SERV:STES:RES?
would return, e.g.
"Total Selftest Status:
PASSED", "Date (dd/mm/yyyy): 09/07/2004 TIME:
16:24:54", "Runtime: 00:06", "...
Usage: Query only
