Return values:
<DefScheme> 1 | 2 | 3
The default color scheme used for the screen, as specified by
the <ci> suffix.
Example:
DISP:CMAP:DEF2
Selects default setting 2 (white background and a black grid) for
screen colors.
DISP:CMAP:DEF?
//Result: 2
Manual operation: See " Screen Colors " on page 222
DISPlay:CMAP<it>:HSL
<hue>, <sat>, <lum>
This command selects the color for various screen elements in the display.
Suffix:
<it>
.
1..n
Selects the item for which the color scheme is to be defined.
Parameters:
<hue> tint
Range: 0 to 1
<sat> saturation
Range: 0 to 1
<lum> brightness
Range: 0 to 1
Example:
DISP:CMAP2:HSL 0.3,0.8,1.0
Changes the grid color.
DISPlay:CMAP<it>:PDEFined <Color>
This command selects a predefined color for various screen elements.
Suffix:
<it>
.
1..n
Selects the item for which the color scheme is to be defined.
Parameters:
<Color> BLACk | BLUE | BROWn | GREen | CYAN | RED | MAGenta |
YELLow | WHITe | DGRay | LGRay | LBLue | LGReen | LCYan |
LRED | LMAGenta
Example:
DISP:CMAP2:PDEF GRE
Manual operation: See "Restoring the User Settings to Default Colors" on page 224
