Remote Control
R&S
®
FSPN
491User Manual 1179.4363.02 ─ 01
DISPlay:THEMe:CATalog?
This command queries all available display themes.
Return values:
<Themes> String containing all available display themes.
Example:
DISP:THEMe:CAT?
Usage: Query only
DISPlay:THEMe:SELect
<Theme>
This command selects the display theme.
Parameters:
<Theme> String containing the name of the theme.
*RST: SPL
Example:
DISP:THEM:SEL "BlueOcean"
Manual operation: See " Theme " on page 222
11.9.4.3 CMAP Suffix Assignment
Several commands to change the color settings of individual items of the display or
printout are available. Which item is to be configured is defined using a <CMAP> suffix.
The following assignment applies:
Suffix Description
CMAP1 Background
CMAP2 Grid
CMAP3 *) Common Text
CMAP4 *) Check Status OK
CMAP5 *) Check Status Error
CMAP6 *) Text Special 1
CMAP7 *) Text Special 2
CMAP8 Trace 1
CMAP9 Trace 2
CMAP10 Trace 3
CMAP11 Marker Info Text
CMAP12 Limit Lines
CMAP13 Limit and Margin Check – "Pass"
CMAP14 Limit and Margin Check – "Fail"
CMAP15 *) Softkey Text
