General Instrument Setup
R&S
®
FSPN
222User Manual 1179.4363.02 ─ 01
└ Selecting the Object......................................................................................223
└ Predefined Colors ........................................................................................ 224
└ Preview ........................................................................................................ 224
Defining User-specific Colors......................................................................................224
Restoring the User Settings to Default Colors............................................................ 224
Theme
The theme defines the colors and style used to display softkeys and other screen
objects.
The default theme is "BlueOcean" .
Remote command:
DISPlay:THEMe:SELect on page 491
Screen Colors
Two different color sets are provided by the instrument, a third user-defined set can be
configured.
The default color schemes provide optimum visibility of all screen objects when regard-
ing the screen from above or below. Default setting is "Default Colors 1" .
If "User Defined Colors" is selected, a user-defined color set can be defined (see
"Defining User-specific Colors" on page 224).
Remote command:
DISPlay:CMAP<it>:DEFault<ci> on page 489
Print Colors
Defines the color settings used for printout.
In addition to the predefined settings, a user-defined color set can be configured (see
"Defining User-specific Colors" on page 224).
If "Show Print Colors on Display" is activated, the currently selected print colors are
displayed as a preview for your selection.
Gui setting Description Remote command
"Optimized Colors" Selects an optimized color setting for the
printout to improve the visibility of the colors
(default setting). Trace 1 is blue, trace 2
black, trace 3 green, and the markers are
turquoise. The background is always printed
in white and the grid in black.
HCOP:CMAP:DEF2
"Screen Colors (Print)" Selects the current screen colors for the
printout. The background is always printed in
white and the grid in black.
HCOP:CMAP:DEF1
"Screen Colors
(Screenshot)"
Selects the current screen colors without any
changes for a screenshot.
HCOP:CMAP:DEF4
"User Defined Colors" Selects the user-defined color setting.
HCOP:CMAP:DEF3
Remote command:
HCOPy:CMAP<it>:DEFault<ci> on page 463
Display Settings
