Build 21 v21.4.1
FEBRUARY 23, 2010 © 2007-2010 RED.COM INC.
117
In record, the Program output provides two independent outputs of 1280 x 720p 10-bit 4:2:2 progressive
scan video, at 59.94 or 50.00 Hz.
In playback, if PLAYBACK is set to 720p, the Program output provides two independent outputs of 1280 x
720p 10-bit 4:2:2 progressive scan video, at 59.94 or 50.00 Hz.
If PLAYBACK is set to 1080p, the Program output provides a 1920 x 1080p 10-bit 4:4:4 RGB progressive
scan video signals at 23.98, 24.00, 25.00, or 29.97 Hz.
NOTE: The Program HD-SDI output provides 4 channels of embedded audio plus timecode.
NOTE: When in Varispeed, the Program output will be blanked.
NOTE: RED ONE outputs progressive scan video, it does not support 1080PsF format.
NOTE: If an ANAMORPHIC record mode has been selected (2K ANA, 3K ANA, 4K ANA) the video
visible on the Program HD-SDI output has been stretched 2:1 to illustrate the final 2.40:1 aspect ra-
tio of the final image projection. The actual recorded image is 1.2:1 aspect.
PREVIEW HD-SDI
A single DIN 1.0/2.3 connector labeled PVW provides a high definition video preview output.
Pin: Signal Description Direction
Center
HD-SDI SMPTE-292M HD-SDI Out
Shield/Screen
GROUND Camera ground --
Preview HD-SDI Output
NOTE: If PREVIEW type is set to MENUS (DVI) the PVW output is disabled.
In record, the Preview output provides a 1280 x 720p 10-bit 4:2:2 progressive scan video, at 59.94 or
50.00 Hz.
In playback, if PLAYBACK is set to 720p, the Preview output provides a 1280 x 720p 10-bit 4:2:2 pro-
gressive scan video, at 59.94 or 50.00 Hz.
If PLAYBACK is set to 1080p, the Preview output provides a 1920 x 1080p 10-bit 4:2:2 progressive scan
video signals at 23.98, 24.00, 25.00, or 29.97 Hz.
NOTE: the Preview HD-SDI output provides 4 channels of embedded audio plus timecode.
NOTE: The embedded timecode value is equal to the Time Code value of the recorded frame pre-
viewed by the PVW output. I.e. the timecode sequence will be discontinuous.
NOTE: RED ONE outputs progressive scan video, it does not support 1080PsF format.
NOTE: If an ANAMORPHIC record mode has been selected (2K ANA, 3K ANA, 4K ANA) the video
visible on the Preview HD-SDI output has been stretched 2:1 to illustrate the final 2.40:1 aspect ra-
tio of the final image projection. The actual recorded image is 1.2:1 aspect.
HDMI
An HDMI Type A connector provides an HDTV compatible 720p video and audio signal, or a DVI / SXGA
compatible 1280 x 848 progressive scan video signal, at 50.00 or 59.94 Hz.
