B. Focus ring: May be adjusted for optimal subject focus for your eye. Available diopter range is +1.5 to -
2.0.
C. Rotary encoder/switch: Used to adjust a variety of parameters. These include the EVF Intensity, but
also camera parameters such as Ch1 Audio Level or Ch 2 Audio Level, and Shutter speed, Varispeed
frame rate and ISO setting. For detailed information on enabling and using this feature, go to EVF
MENU under DISPLAY in PREFERENCES under SETUP in SYSTEM MENU CONTROLS.
D. Two (2) programmable USER KEY 3 and 4 buttons.
• Default setting of USER KEY 3 turns COLOR TOOLS (monochrome or false color) On/Off.
• Default setting of USER KEY 4 turns the METER (e.g. WAVEFORM or FOCUS ASSIST) On/Off.
• USER KEY 3 and 4 can be programmed. Refer to KEY-MAP under PREFERENCES in SET UP un-
der SYSTEM MENU CONTROLS.
E. One (1) fixed function button.
• The fixed function button (located closest to the focus ring) selects 1:1 FOCUS CHECK mode.
When selected this shows the central region of the MYSTERIUM sensor in native 4K resolution.
NOTE: This function is not available during RECORD.
EXTERNAL HD-SDI OR HDMI MONITORS
External monitors can be connected to the camera through the HDMI and HD-SDI (2) ports located on the
side of the camera. Refer to CAMERA CONNECTORS.
To aid external monitor alignment, the RED ONE camera provides a range of test signals including SMPTE
Bars, Back and White Fields, Luma and Chroma Ramps, and a Chip Chart. Refer to TEST SIGNAL under
MONITOR in SYSTEM MENU CONTROLS.
NOTE: The internal test signals cannot be recorded; they are provided to align external video re-
corders or monitors connected to the camera via the HD-SDI or HDMI ports.
TROUBLESHOOTING EXTERNAL MONITORS
If after connecting the camera to an external monitor and the camera display is not shown completely on
the monitor display, press SYSTEM menu button, select MONITOR and try the following:
• Select PREVIEW and change setting between MENUS [DVI] or VIDEO [720p].
• Select HD-SDI and change setting between 50.00 HZ or 59.94 HZ.
