4-110 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
Signal Specication
+5 V
Repeater supply
+5 V ( ±10%)
max. 75 mA
Repeater control signal TTL compatible 1: transmit
0: receive
Output resistance: 350 R
V
OL
<= 0.8 V at I
OL
<= 2 mA
V
OH
>= 3.5 V at I
OH
<= 1 mA
Receive/send data EIA-RS485 standard
Fig. 4-186: Signal specication
CAUTION
Danger of destroying output
"+5V Repeater supply" with overload!
 do not short
 do not exceed maximum current
The denition of the displays are in the rmware.
Signal Specication:
Diagnostic display
H30 – H33:
