Rexroth Indramat ECODRIVE03 Series User Manual

610-3.**CKD 30EVIRDOCEsrellortnoC evirD 30EVIRDOCE 5-17
Connections on top of the drive controller
Fa5143f1.fh7
X3:
digital in-/ outputs
X10:
expansion interface
XS3:
holes for cable ties to x
cable shields
Fig. 5-20: Connections on top of unit for DKC**.3-016-7-FW
