June 21, 2002
Publication No. PI9780
9
RFL Part Number (fill in blanks): 9780
Base System
9780 Transmitter/Receiver TR
9780 Transmit only TX
9780 Receive only RX
Power Supply
48 to 125 Vdc Single Supply 1
48 to 125 Vdc Dual Supplies 2
250 Vdc Single Supply 3
250 Vdc Dual Supplies 4
External Supplies 5
10 W Power Amplifer and Power Output Filter
External amplifier or Rx Only 0
30 to 65 KHz, 10 W 1
65 to 156 KHz, 10 W 2
156 to 392 KHz, 10 W 3
392 to 535 KHz, 10 W 4
114 to 288.5 KHz, 10W 5
Relay Control Voltage I/O
48 Vdc 1
125 Vdc 2
250 Vdc 3
Logic Level Interface 4
Receive Bandwidth
Tx Only 0
200 Hz - Line Frequency 50 Hz 1
500 Hz - Line Frequency 50 Hz 2
1000 Hz - Line Frequency 50 Hz 3
200 Hz - Line Frequency 60 Hz 4
500 Hz - Line Frequency 60 Hz 5
1000 Hz - Line Frequency 60 Hz 6
RF Interface
Tx Only or Rx Only A
Single Tx/Rx port with skewed hybrid B
Three ports (Tx, Rx, Spare) no hybrid C
Three ports (Tx, Rx, Tx/Rx) with hybrid D
Three ports (Tx, Rx, Tx/Rx) with hybrid, and ext. hybrid
connections
E
Three ports, with X hybrid and Skewed Hybrid
F
Sequence of Events
No SOE Module 0
With SOE Module 1
Other Custom Configuration
No user specified customization A
Phase Comparison Application B
External Hybrid Chassis C
Additional system details provided by customer Z
*- For Rx/Rx please consult the factory
RFL 9780 FSK Powerline Carrier Tx/Rx, Tx only or Rx only
Smart Number Ordering Information
