RFL Electronics 9780 - Page 31

June 21, 2002
Publication No. PI9780
10
RFL Part Number (fill in blanks): 9780 TT
Base System
Chassis, motherboard & standard modules TT
Power Supply
48 to 125 Vdc Dual Supplies 1
250 Vdc Dual Supplies 3
External Supplies 5
10 W Power Amplifer and Power Output Filter (F1)
External amplifier 0
30 to 65 KHz, 10 W 1
65 to 156 KHz, 10 W 2
156 to 392 KHz, 10 W 3
392 to 535 KHz, 10 W 4
114 to 288.5 KHz, 10W 5
10 W Power Amplifer and Power Output Filter (F2)
External amplifier 0
30 to 65 KHz, 10 W 1
65 to 156 KHz, 10 W 2
156 to 392 KHz, 10 W 3
392 to 535 KHz, 10 W 4
114 to 288.5 KHz, 10W 5
Relay Control Voltage
48 Vdc 1
125 Vdc 2
250 Vdc 3
RF Interface
Single Port TX/TX with Transformer Hybrid A
Three Port TX/TX without Hybrid B
Three Port TX/TX with X Hybrid and Skewed
Hybrid
C
Sequence of Events
No SOE Module 0
With SOE Module 1
Other Custom Configuration
No user specified customization 0
Additional system details provided by customer 1
RFL 9780 FSK Powerline Carrier Tx/Tx
Smart Number Ordering Information
