Part D - Maintenance cobas p 512
4-20 Operator's Manual - Version 1.6 - 09/2015
4.6.5 Emptying the condensation container
Empty the condensation container as necessary or during monthly maintenance procedures
at the latest. The container is found inside the output sorter.
1. Switch off the compressed air supply for the system.
2. Disconnect the compressed air connection at the rear of the device.
3. Open the door of the output sorter.
4. Attach a fitted piece of hose to the drain valve.
5. Turn the drain value ¼ turn in the indicated direction clockwise. The condensation
drains out. Use a container to catch the water.
Figure 4-22: Drain valve on the maintenance unit
A
Maintenance unit
B
Condensation drain valve on the maintenance unit
A
B
