Roche cobas p 512 - Replacing the Lighting of Tube Type Identification Module

Part D - Maintenance cobas p 512
4-26 Operator's Manual - Version 1.6 - 09/2015
4.7.2 Replacing the lighting of tube type identification module
The lighting (consisting of three bulbs) in the tube type identification module must be
replaced once a year.
CAUTION
The bulbs are very hot! They can take up to 15 minutes to cool down!
4.7.2.1 Replacement parts
See spare part list
4.7.2.2 Replacing the light bulbs
Proceed as follows to take apart the lighting:
1. Switch the system off at the mains switch.
2. Unscrew the fastening screws on the front and rear of the housing panel.
Figure
4-33: Housing panel, rear
Figure
4-34: Housing panel, front
A
Fastening screws on the housing
3. Remove the front and rear housing panels.
A
