Part B - System description cobas p 512
2-12 Operator's Manual - Version 1.6 - 10/2015
2.2.6 Input sorter
The sample tubes are fed to the system (loaded) by the input sorter. It is possible to load the
output sorter by replacing the complete rack trays or by inserting individual racks or tubes.
The loading can take place during routine operation at any time with the drawer open.
Figure 2-5: Input sorter with gripper
A
Sorter unit
B
Rack
C
Drawer
A
B
C
