Part A - General information cobas p 512
1-26 Operator's Manual - Version 1.6 - 10/2015
Label placement on the
sample tube
Bar code label must be within
the scanning area.
(Label to tube opening, cap or
plug)
5 - 8 mm
b = 75 mm - 20 mm =
max. 55 mm
Window for serum
analysis
(QS I system)
In order for the content of the
tube to be analyzed, an area
should remain clear with the
size
c = min. 6.5 mm.
This must also be guaranteed
even when the label is placed on
slanted or skewed.
