Rotax 125 MAX evo Repair Manual

BRP-Rotax
REPAIR MANUAL
SYSTEM DESCRIPTION
Overview Position on engine
Figure 6.1: Position on engine, TYPICAL (Figure shows 125 MAX evo engine)
1 Intake silencer 2 Carburetor
3
Fuel pump
Chapter 6
Page 2
Effectivity: 125 MAX evo, Junior MAX
evo, Mini MAX evo, Micro MAX evo
Edition - February 01 2018 /Rev. 0
