Rotax 125 MAX evo Repair Manual

BRP-Rotax
REPAIR MANUAL
Figure 3.2: Battery
1
Battery cover
2
O-ring
3
Allen screw with rounded flange head
4
Positive battery terminal
5
Negative battery terminal
______________________________________________________
Instruction See Figure: Ignition system.
4. Pull the spark plug connector (1) off the spark plug. Minimum removal force 30 N.
5. Remove the cable tie (11).
6. Disconnect the plug connections (6) on the ignition coil (2).
7. Disconnect the plug connection (7) on the solenoid valve (5).
8. Disconnect the connector (9) for the pick up sensor (3)
9. Disconnect the connector (10) for the starter (4).
Chapter 3
Page 4
Effectivity: 125 MAX evo, Junior MAX
evo, Mini MAX evo, Micro MAX evo
Edition - February 01 2018 /Rev. 0
