BRP-Rotax
REPAIR MANUAL
PREPARATION FOR REMOVAL
Safety
instructions
m WARNING
Danger of severe burns and scalds!
Always allow the engine to cool down to ambient temperature before starting any work.
REMOVAL OF THE IGNITION SYSTEM
Safety
instructions
m WARNING
Risk of electric shock!
Ignition “OFF” and system grounded! Disconnect negative terminal of battery.
NNOOTTEE
When disconnecting the battery be sure to always disconnect the negative termi-
nal before the positive terminal. Remember that when the engine is running the
ignition system has a high voltage of 35 kV; the spark plug therefore must not be
removed with the engine running.
Instruction Proceed as follows to disconnect battery. See Figure: Battery.
1. Remove the Allen screw with rounded flange head M6x20 (3) with O-ring 5x2 (2).
2. Remove the battery cover (1).
3. Disconnect the negative battery terminal (5).
Effectivity: 125 MAX evo, Junior MAX
evo, Mini MAX evo, Micro MAX evo
Edition - February 01 2018 /Rev. 0
Chapter 3
Page 3
